Uflex Underfloor Heating
)
Grant’s Uflex system makes underfloor heating a viable option for a wide range of projects, from one-off new build projects and room extensions through to larger multi-property developments. The Uflex underfloor heating system is embedded into the floor construction so is ideally suited for new builds whereby the pipework is fitted during the initial stages of the property’s development. The Uflex pipework is then positioned and clipped into place once the flooring’s insulation and membrane has been fitted, after which a flow screed is laid over the top and allowed to fully dry before the heat source is introduced.
- Ideal for new builds, extensions & larger developments
- Straightforward to position, secure & install
- Install with PE-RT and PEX-AL-PEX pipe
Features & benefits
- *25 year guarantee (pipework only)
- Compatible with PE-RT and WRAS approved PEX-AL-PEX pipe which are supplied by Grant UK. Both the PE-RT and PEX-AL-PEX pipe are 16mm in diameter, flexible and easy to work. PEX-AL-PEX pipe offers the additional benefit of being suitable for other general plumbing uses as well
- Easy to install with the back-up support from Grant UK also available with system design assistance
- Grant's Uflex uses a flow screed system, as opposed to a solid screed system, meaning that the drying time is much quicker with the flow screed mix drying in thirty days
- Uses a unique edge insulation consisting of a self-adhesive edging strip which is located around the surrounds of the area in which the screed will be laid. This strip comes with a ‘skirt’ design which provides an overhang which curves alongside the wall. This edging strip not only contains and seals the screed, it also serves to reduce heat loss out via the walls
- The Uflex pipework layout can be easily divided into zones allowing for zone control to deliver complete comfort to homeowners
- Grant Uflex has a quick reaction time - working with room thermostats, the system’s temperature can be easily adjusted without needing to switch the heating on or off which, over time, can reduce the overall demand on the heat source
- Using ‘setback’ controls, the Uflex system can run continuously, setting back to lower floor temperatures during unoccupied periods and using less energy to reheat the floor when the temperature demand increases
- Heat emission plates available for UFH installations for suspended floors
