Duo Thin Flat Concrete Roof Tile
)
)
)
)
The FP McCann Duo Thin Flat Roof Tile is a contemporary interlocking concrete tile engineered to offer the refined look of natural slate with the practical advantages of modern roofing systems.
Featuring a thin leading edge and flat profile, the Duo Thin Flat tile creates a clean, minimalist roof finish that blends seamlessly with both traditional and modern architectural designs. It is particularly suited to projects where a slate-effect aesthetic is required without the cost and installation complexity of natural slate.
Its interlocking design enables a single-lap installation, meaning fewer tiles are required per square metre compared to traditional plain tiles. This helps to reduce installation time and overall project costs, while still delivering a secure and weather-resistant roof covering.
Manufactured from high-quality concrete, the Duo Thin Flat tile provides excellent durability and resistance to harsh UK weather conditions, ensuring long-lasting performance with minimal maintenance.
Key Features & Benefits
- Slate-effect appearance: Mimics small-format natural slate for a premium finish
- Thin leading edge design: Creates a sleek, low-profile and modern roofline
- Interlocking system: Provides a secure, weather-tight roofing solution with reduced tile usage
- Fast installation: Single-lap design reduces labour time and installation costs
- Durable concrete construction: Built to withstand wind, rain, and frost conditions
- Versatile aesthetic: Suitable for both contemporary and traditional applications
- Sustainable production: Manufactured using responsible processes and materials
Specifications
- Material: Concrete
- Tile size: Approx. 420mm x 334mm
- Thickness: Approx. 21mm
- Weight per tile: Approx. 4.7kg
- Cover width: Approx. 305mm
- Minimum headlap: 75mm
- Minimum pitch:
- 22.5° (75mm headlap)
- 17.5° (100mm headlap)
- Maximum gauge: Approx. 345mm
- Covering capacity:
- ~9.7 tiles/m² (75mm headlap)
- ~10.5 tiles/m² (100mm headlap)
Applications
Ideal for use in:
- Residential new builds and housing developments
- Roof refurbishments and re-roofing projects
- Contemporary architecture requiring a low-profile finish
- Traditional designs needing a slate-effect appearance
- Pitched roofing systems in both domestic and commercial settings
The FP McCann Duo Thin Flat Roof Tile combines modern aesthetics, efficient installation, and long-term performance, making it a versatile and cost-effective alternative to natural slate for a wide range of roofing projects.
