Midea H Pack Indoor Monoblock Heat Pump
The H-Pack offers a compact, silent, and highly flexible heating solution that eliminates the need for an outdoor unit—an important advantage in areas with noise restrictions, limited space, or strict building regulations.
With the H‑Pack, Midea addresses key industry challenges such as high installation complexity and space constraints, providing an alternative that simplifies the transition toward sustainable heating while maintaining system reliability.
A New Standard in Ease of Installation
The H‑Pack Indoor Hybrid Heat Pump is engineered for fast, user‑friendly installation:
- No outdoor unit—ducted air intake/outlet keeps the exterior façade clean and quiet.
- Opening opportunities for a broad installer base.
- Front‑service design with quick‑release access and modular components simplifies maintenance.
- Flexible piping and duct options support installation in attics, cellars, technical rooms, or outbuildings.
The optional Midea HydroBox further streamlines installation by integrating all key hydraulic components into a compact module, reducing installation time from one full working day to about one hour, while lowering cost significantly.
Compact, Silent, and Powerful
Despite its small footprint, the H‑Pack delivers robust performance:
- Energy class A+++ / A++
- Up to 70°C outlet temperature
- Low noise operation supported by extensive EPP insulation
- R290 refrigerant for sustainable, future‑proof performance
By placing all components indoors, the system avoids visual impact outdoors and minimizes weather‑related efficiency losses.
Hybrid-Ready for Maximum Flexibility
The H‑Pack indoor unit supports hybrid operation by seamlessly combining heat pump technology with fossil boilers. This flexibility ensures:
- Optimal use of renewable and cost‑efficient energy sources
- Consistent heating performance during extreme low temperatures
- Compliance with national renewable energy requirements (e.g., Germany’s 65% rule)
- Continued heating even if one energy source is temporarily unavailable
Compatibility includes OpenTherm, ON/OFF, 0–10V, and Modbus, ensuring easy integration with third‑party boilers and control systems.
Advanced Control and Smart Home Integration
The system includes a full‑color touchscreen controller with:
- Intuitive menu structure
- OTA updates
- Dual-zone control capabilities
- Startup and configuration wizard
- Energy monitoring and scheduling
- Hybrid optimization tools (tariffs, bivalent points, cost settings)
Through the Midea App, users can monitor energy consumption, manage heating and DHW settings, activate silent or boost modes, and receive system notifications. Installers benefit from remote diagnostics via the Service App, reducing service effort and downtime.
Preparing Homes for an All-Electric Future
Consumers can start with a hybrid setup and later switch to fully electric heating simply by exchanging the HydroBox module—offering a scalable transition path toward complete electrification without replacing the main heat pump unit.
Availability
The H‑Pack Indoor Hybrid Heat Pump and HydroBox lineup—including both hybrid and all-electric versions—will enter mass production in 2026, with shipments to the UK planned within the same year.
